PLA – UPS THREE PHASE, DOUBLE CONVERSION, SINE WAVE, from 10 to 600KVA
PLA is a true on-line UPS, double conversion technology with high efficiency. Input and Output voltages are three-phase. Rating power available from 10kVA to 200kVA. High performance and high efficiency with PF 0,9 and 1.0. PLA uses power modular technology and it works in redundance mode N+x. It is a flexible system, in fact is possible to add or remove power cabinets depending by the amount of load to supply. In this way it is possible to optimize the financial investments by escalating the configuration according to the real needs. PLA can be used for any kind of load: IT, AUTOMATIC MACHINE, DATA CENTER, HOSPITAL, INDUSTRY, etc. PLA can solve every kind of problems, such as blackouts, spikes, voltage disturbances, frequency disturbances, harmonic distortion (THD <2%) current noise, brownouts, surges, and so on. PLA series uses a Digital Signal Processor (DSP) control to increase the reliability, the efficiency, and for auto protection and auto diagnosis. PLA series keep input current balanced. No unbalance problems may occur during the operation.
MAIN FEATURES
- True On-line UPS input three-phase + N, output three-phase + N
- Switching time 0 ms
- Power factor 0,9 – (optional 0,8)
- LCD display
- Modular power from 10kVA to 200kVA
- DSP (Digital Signal Processor)
- Input Low distortion < 2%
- ECO mode function
Optional: SNMP, MODBUS, RELAY. Standard: USB port, RS485, EPO contact
MODULAR POWER TECHNOLOGY
Modular power technology used for PLA series is an easy “Parallel concept”.
PLA series has an intelligent sensor which automatically detects other UPSs with same power.
No settings via software, no parallel boards needed, UPS it is always ready and with a self test reset and adjust its
output power.
Parallel control cables are shielded with double isolation to avoid noise interference.
The cables are connected in ring mode, as shown in the picture below.
Ring connection is very reliable.
The parallel configuration guarantees an higher reliability than a single “full power” UPS. For making a correct
configuration it is important to meet the items written below:
1) Every UPS must have the same power and connected to the same by-pass line .
2) The electric cables (input, output, by-pass) must have the same length and same characteristic
| MODEL | PLA10 | PLA15 | PLA20 | PLA30 | PLA40 | |||
| Input | Power | 10KVA
9KW |
15KVA
13.5KW |
20KVA
18KW |
30KVA
27KW |
40KVA
36KW |
||
| Phases | 3 Steps 4 Cables and Grounding | |||||||
| Rated voltage | 380/400/415Vac | |||||||
| Voltage Range | 208~478Vac | |||||||
| Frequency Range | 45-55Hz to 50Hz / 56-66Hz to 60Hz (auto detection) | |||||||
| Power factor | ≥0.99 | |||||||
| THDi Current | ≤2%(100% non-linear load) | |||||||
| Bypass voltage range | Max. voltage: 220Vac:+25% (optional +5%,+10%,+15%) 230Vac:+20% (optional +10%,+15%) 240Vac:+15% (optional +10%) |
|||||||
| Min. Voltage: -45% (optional -20%、-30%) | ||||||||
| Frequency Protection Range: ±10% | ||||||||
| Generator Set Input | Supported | |||||||
| Output | Phases | 3 Steps 4 Cables and Grounding | ||||||
| Rated voltage | 380/400/415Vac | |||||||
| Power factor | 0.9 | |||||||
| Voltage regulation | ±1% | |||||||
| Frequency | With network | ±1%、±2%、±4%、±5%、±10% of rated frequency (optional) | ||||||
| In battery mode | (50/60±0.1%) Hz | |||||||
| Crest factor | 3:1 | |||||||
| THD | ≤1% with linear load | |||||||
| ≤3% with nonlinear load | ||||||||
| Efficiency (in normal mode) | ≥96.5% | ≥97.5% | ||||||
| Battery | Voltage | UPS standard: ±120Vdc (10+10) 12V 7/9AH
Long autonomy UPS ±96V/±108V/±120Vdc (16/18/20 pcs. Optional) |
UPS standard: ±240Vdc (20+20)
Long Range UPS: ±192/±204/±216/±228/±240Vdc (32/34/36/38/40 pcs optional) |
|||||
| Charging Current(A) | The charging current is automatically set according to the capacity, quantity and dynamics of the batteries inserted
UPS standard (20pcs): 1,35A UPS standard (2X20pcs): 2,7A UPS standard (3X20pcs): 4,5A Long Range UPS: Max 10A |
|||||||
| Battery Test | Set by Default to run the test every 30 days | |||||||
| Transfer Time | Mains to battery: 0ms
Network to Bypass: 0ms |
|||||||
| MODEL | PLA10 | PLA15 | PLA20 | PLA30 | PLA40 | ||
| Protection | Overload | Normal Mode | Load≤110%: duration 60min, ≤125%: duration 10min, ≤150%: duration 1min
≥150% immediately switches to bypass |
||||
| Battery Mode | Load≤110%: 10min duration, ≤125%: 1min duration, 150%: 10s duration
≥150% immediately turns off the UPS |
||||||
| Bypass mode | 20A Switch | 32A Switch | 40A Switch | 63A Switch | 80A Switch | ||
| Short Circuit | Involves the entire UPS | ||||||
| Overheating | Normal Mode: Switch to Bypass,
Battery mode: Immediately shuts down the UPS |
||||||
| Low battery | UPS Alarm and Shutdown | ||||||
| Self-diagnosis | When UPS is switched on and via software command | ||||||
| EPO (optional) | Immediately turns off the UPS | ||||||
| Battery | Advanced battery management | ||||||
| Noise suppression | Conform to there EN62040-2 | ||||||
| Alarms | Sound and Visual | Mains failure, low battery, overcharging, UPS failure | |||||
| Display | LED and LCD status | Line Mode, Bypass Mode, Low Battery, Low Battery, Overcharge, and UPS Fault | |||||
| Displayed on the LCD screen | Input Voltage, Input Frequency, Output Voltage, Output Frequency, Load Percentage, Battery Voltage and Internal Temperatures etc. | ||||||
| Communication Interface | USB, RS485, Parallel (optional), EPO, Dry Contacts, Smart Slot, SNMP Card (optional), Relay Board (optional) | ||||||
| Environment | Operating Temperature | 0°C~40°C | |||||
| Storage Temperature | -25°C~55°C | ||||||
| Humidity | 0~95% non-condensing | ||||||
| Altitude | < 1500m. When >1500m the rated power is reduced | ||||||
| Noise | < 55dB | < 58dB | |||||
| More | Degree of protection | IP20 | |||||
| Group Dimensions (P×L×H) | 828x250x868 | ||||||
| Weight (kg)
without batteries |
42 | 45 | 45 | 71 | 72 | ||
| Units | 1 | ||||||
| Complies with safety regulations | CE,EN/IEC 62040-3,EN/IEC 62040-1-1, EN/IEC60950-1, IEC61000-4-2, IEC61000-4-3, IEC61000-4-4, IEC61000-4-5, IEC61000-4-6, IEC61000-4-8 | ||||||
| Frequency Converter Function | YES (see PLA-FC range) | ||||||
| MODEL | PLA3060 | PLA3080 | PLA3100 | ||
| Technology | On-line Double Conversion | ||||
| Input | Power (kVA/kW) * | 60/60 | 80/80 | 100/100 | |
| Phases | 3 Phase + Neutral + Grounding | ||||
| Rated voltage | 380/400/415Vac | ||||
| Voltage Range | 138~485Vac | ||||
| Frequency Range | 40Hz – 70Hz | ||||
| Power factor | ≥0.99 | ||||
| THDi Current | ≤3% | ||||
| Bypass voltage range | Max. voltage: 220Vac:+25% (optional +10%,+15%,+20%) 230Vac:+20% (optional +10%,+15%) 240Vac:+15% (optional +10%) |
||||
| Min. Voltage: -45% (optional -20%,-30%) | |||||
| Frequency Protection Range: ±10% | |||||
| Generator Set Input | Supported | ||||
| Output | Phases | 3 Phase + Neutral + Grounding | |||
| Rated voltage | 380/400/415Vac | ||||
| Power factor | 1.0 | ||||
| Voltage regulation | ±1% | ||||
| Frequency | With mesh | Synchronized with the input, when the input frequency is > ±10%
(±1%, ±2%, ±4%, ±5% – optional) |
|||
| In battery mode | 50/60*(1±0.02%) Hz | ||||
| Crest factor | 3:1 | ||||
| THD | ≤2% with linear load | ||||
| ≤4% with nonlinear load | |||||
| Efficiency (in normal mode) | 95,5% | ||||
| Battery | Voltage | ±180V/±192V/±204V/±216V/±228V/±240/±252/±264/±276/±288/±300Vdc (30/32/34/36/38/40/42/44/46/48/50pcs optionale)
360Vdc~600Vdc (30~50 pcs) 36 pcs standard, 36~50pcs PF output 1; 32~34pcs PF output 0.9; 30pcs PF output 0.8) |
|||
| Charging Current(A) | The charging current is automatically set according to the capacity, quantity and dynamics of the batteries inserted
Max 30A |
||||
| Max 20A | Max 40A | ||||
| Battery Tests | Set by Default to run the test every 30 days | ||||
| Transfer Time | Mains to battery: 0ms
Network to Bypass: 0ms |
||||
| MODEL | PLA360 | PLA380 | PLA3100 | |
| Protection | Overload | Load≤110%: Duration 60min, ≤125%: Duration10min, ≤150%: Duration 1min,
>150% immediately switches to bypass |
||
| Alarms | Sound and Visual | Mains failure, low battery, overcharging, UPS failure | ||
| Display | LED and LCD status | Line Mode, Bypass Mode, Low Battery, Low Battery, Overcharge, and UPS Fault | ||
| Displayed on the LCD screen | Input Voltage, Input Frequency, Output Voltage, Output Frequency, Load Percentage, Battery Voltage and Internal Temperature | |||
| Communication Interface | USB, RS232, RS485, REPO, Parallel (optional), opto-isolated contacts,
LBS port, Backfeed port, Smart Slot, SNMP Card (optional), Relay Card (optional) |
|||
| Environment | Operating Temperature | 0°C~40°C | ||
| Storage Temperature | -25°C~55°C (without batteries) | |||
| Humidity | 0~95% non-condensing | |||
| Altitude | < 1500m when >1500m reduces the rated power | |||
| Noise | < 60dB | < 62dB | < 63dB | |
| More | UPS Dimensions (P×L×H) cm | 828x250x868 | 850x442x1200 | |
| UPS Weight (Kg)
without batteries |
83 | 154 | 161 | |
| Installation Type | Vertical | |||
| Media Type | Wheels | |||
| Complies with safety regulations | IEC/EN62040-1, IEC/EN62040-2, IEC/EN62040-3, IEC/EN60950-1 | |||
| Frequency Converter Function | YES (request technical data sheet dedicated to the PLA3-FC version) | |||
* Intermediate ratings and up to max 600kVA can be obtained by connecting a maximum of 6 UPS of the same size in parallel.
