ISP – SINGLE PHASE SEPARATION TRANSFORMERS from 10VA to 50VA
SINGLE PHASE SEPARATION TRANSFORMERS from 10VA to 50VA
| Standard input voltage 230V Open type construction IP00 protection degree Isolation class E (AT max 40°C) Frequency 50/60Hz Separated copper windings cl. F-H Resin impregnated and tropicalized Protected terminal blocks or flying leads on request Earth terminal Applied standards: EN61558-2-1 Last 3 digits of the code correspond to input/output voltage combination |
 |
  |
| power VA |
part no. | dimensions mm | weight kg |
box | |||||
| W | D | H | d | e | f | ||||
| 10 | ISP010… | 68 | 58 | 80 | 50 | 47 | 4 | 0.6 | MBT01 |
| 15 | ISP015… | 68 | 58 | 80 | 50 | 47 | 4 | 0.7 | MBT01 |
| 20 | ISP020… | 68 | 58 | 80 | 50 | 47 | 4 | 0.75 | MBT01 |
| 25 | ISP025… | 68 | 61 | 80 | 50 | 50 | 4 | 0.85 | MBT01 |
| 30 | ISP030… | 68 | 66 | 80 | 50 | 55 | 4 | 0.9 | MBT01 |
| 40 | ISP040… | 75 | 61 | 85 | 60 | 60 | 5 | 0.95 | MBT01 |
| 50 | ISP050… | 75 | 76 | 85 | 60 | 76 | 5 | 1 | MBT01 |
